As core energy storage devices in the current new energy field, lithium batteries are widely used in new energy vehicles, energy storage systems, consumer electronics and other fields due to their high energy density and long cycle life. Among them, nickel-cobalt-manganese ternary lithium batteries (referred to as NCM lithium batteries) and lithium iron phosphate batteries (referred to as LFP lithium batteries) are the two mainstream technical routes in the market. There are significant differences between the two in terms of core materials, performance, cost control and application scenarios. This article will conduct a detailed comparative analysis from multiple dimensions.

The core performance of a battery is determined by its cathode material. The fundamental difference between NCM lithium batteries and LFP lithium batteries lies in the choice of cathode material, which directly leads to a series of differences in subsequent performance.

The cathode material of NCM lithium batteries is nickel-cobalt-manganese ternary composite oxide, where "N", "C" and "M" in the name correspond to nickel, cobalt and manganese respectively. By adjusting the ratio of the three elements (such as common ratios like NCM523, NCM622, NCM811), differentiated optimization of battery performance can be achieved. High nickel content (such as NCM811) can significantly improve energy density, but it also has higher requirements for production processes and safety. The anode material is mostly graphite, the electrolyte is a mixture of lithium salts such as lithium hexafluorophosphate and organic solvents, and the separator is usually a polyethylene or polypropylene porous membrane.

The cathode material of LFP lithium batteries is lithium iron phosphate (LiFePO₄), which has an olivine structure with extremely strong crystal stability. Its anode is also mainly graphite, and the selection of electrolyte and separator is similar to that of NCM lithium batteries, but in some scenarios, the electrolyte formula will be adjusted according to safety requirements. Compared with NCM ternary materials, lithium iron phosphate materials do not contain precious metals such as cobalt and nickel, so their raw materials are more widely available. Moreover, the strong P-O bonds in the structure make it less likely to collapse during charging and discharging.

Performance parameters are the core indicators to measure the applicability of batteries. The two have significant differences in energy density, safety, cycle life, low-temperature performance, etc. The specific comparison is as follows:

Energy density refers to the electrical energy that a battery can store per unit mass or volume, which directly determines the endurance of terminal products (such as the range of new energy vehicles). The layered structure of the ternary material of NCM lithium batteries is conducive to lithium ion intercalation/deintercalation, and the increase in nickel content can further increase lithium ion storage, so its energy density is significantly higher than that of LFP lithium batteries. At present, the system energy density of mass-produced NCM lithium batteries can reach 180-250 Wh/kg, and high-nickel systems (such as NCM811) can even exceed 300 Wh/kg. The system energy density of LFP lithium batteries is usually between 120-180 Wh/kg. Although it has been improved in recent years through structural innovation (such as blade batteries), it is still lower than that of NCM lithium batteries.

Safety is the primary prerequisite for battery applications. The difference between the two stems from the chemical stability of the cathode material. The lithium iron phosphate cathode of LFP lithium batteries has a stable olivine structure. When the battery is subjected to abuse such as extrusion, puncture, and high temperature, it is not easy to decompose thermally, and it is more difficult to trigger "thermal runaway". However, the ternary material of NCM lithium batteries has poor thermal stability, especially high-nickel ternary materials, which are easy to decompose and release oxygen at high temperatures, react with the electrolyte to release a lot of heat, and then induce thermal runaway, so the safety is relatively low. From the perspective of practical application cases, LFP lithium batteries are more widely used in scenarios with high safety requirements such as energy storage power stations and low-speed electric vehicles.

Cycle life refers to the number of charge-discharge cycles when the battery capacity decays to 80% of the initial capacity during the charge-discharge process, which is directly related to the use cost and service life of the battery. The lithium iron phosphate material of LFP lithium batteries has a stable structure, and the crystal structure changes little during long-term charge-discharge cycles. Its cycle life can usually reach 2000-3000 times, and some high-quality products can even exceed 5000 times. However, the ternary material of NCM lithium batteries is prone to layered structure collapse and metal ion dissolution during cycles, so its cycle life is relatively short, generally 1500-2000 times. The high-nickel system has a shorter cycle life due to its more unstable structure.

Low-temperature performance directly affects the use effect of the battery in cold areas, which is mainly related to the lithium ion diffusion rate of the cathode material and the conductivity of the electrolyte. The ternary material of NCM lithium batteries has a faster lithium ion diffusion rate in low-temperature environments, and the low-temperature fluidity of the electrolyte is also better. Therefore, in a low-temperature environment of -20℃, it can still maintain a capacity output of more than 70%. However, the lithium ion diffusion resistance of the lithium iron phosphate material of LFP lithium batteries increases at low temperatures, and the conductivity of the electrolyte decreases. In the same low-temperature environment, the capacity output is usually only 50%-60%, which needs to be improved by adding low-temperature additives or improving the electrode structure.

Battery cost is mainly determined by core components such as cathode materials, anode materials, and electrolytes. The ternary material of NCM lithium batteries contains precious metals such as cobalt and nickel. Among them, cobalt is expensive and its resources are unevenly distributed (mainly concentrated in regions such as the Democratic Republic of the Congo), resulting in its cathode material cost accounting for 40%-50% of the total, and the overall battery cost is high. However, the lithium iron phosphate material of LFP lithium batteries does not contain cobalt and nickel, and its raw materials are cheap and abundant (iron and phosphorus are in sufficient reserves in my country). The cost of cathode materials accounts for only 20%-30% of the total, and the overall battery cost is 10%-20% lower than that of NCM lithium batteries, which has obvious advantages in scenarios sensitive to cost.

Based on the above performance differences, NCM lithium batteries and LFP lithium batteries have formed a differentiated application pattern, adapting to different terminal needs respectively:

Due to its high energy density and excellent low-temperature performance, NCM lithium batteries are more suitable for scenarios with high requirements for endurance and low-temperature adaptability. The core application fields include: ① Mid-to-high-end new energy passenger vehicles, such as Tesla Model 3/Y (some versions), BYD Han EV (some versions), etc., which need to achieve long endurance through high energy density; ② Consumer electronic products, such as laptops, drones, etc., which need to store more electrical energy in a limited volume; ③ New energy commercial vehicles in northern regions, which need to adapt to normal use in cold climates.

Relying on the advantages of high safety, long cycle life and low cost, LFP lithium batteries are mainly used in scenarios sensitive to safety and cost, including: ① Energy storage systems, such as large-scale photovoltaic energy storage power stations, power grid peak-shaving energy storage projects, etc., which need to operate stably for a long time and avoid safety risks; ② Mid-to-low-end new energy passenger vehicles and commercial vehicles, such as BYD Qin PLUS EV (some versions), new energy logistics vehicles, etc., which have high requirements for cost control; ③ Two-wheeled electric vehicles, such as high-end models of brands such as Yadea and Aima, which need to balance safety and service life.

NCM lithium batteries and LFP lithium batteries are not in a "substitution relationship" but a "complementary relationship". The two occupy different market shares relying on their core advantages of "high energy density" and "high safety + low cost" respectively. From the perspective of development trends, the future direction of NCM lithium batteries is "high nickel content + cobalt-free", which further improves energy density by increasing nickel content and develops cobalt-free ternary materials to reduce costs. The development direction of LFP lithium batteries is "high energy density + fast charging", which improves energy density through nano-cathode materials and improved battery structures (such as blade batteries and square lamination), and optimizes electrolytes to achieve fast charging performance improvement. In the future, with continuous technological breakthroughs, the performance gap between the two may gradually narrow, but the differentiated application pattern will still exist for a long time.
